National VI diesel version of aviation catering vehicle - chassis

National VI diesel version of aviation catering vehicle - chassis

National VI diesel version of aviation catering vehicle - chassis

It adopts the Qingling QL5190TZZAEQHY type /QL1110ANPAY type chassis, equipped with a overhead camshaft, 6HK1-TCG61 water-cooled in-line direct injection 6-stroke diesel engine, with emissions meeting National VI standards, an integrated cycle ball steering mechanism (with power steering), and a hydraulic dual-circuit foot brake for starting. 24V DC electrical system

The cab is equipped with air conditioning for both heating and cooling, a hydraulic booster, an AM/FM radio, and luxury interior lighting

The underframe is generally a frame structure, consisting of a main beam frame, a front platform bracket, and four hydraulic support feet. It can ensure safe operation in winds of force 8 and maintain the stability of the vehicle body in winds of force 12. The safety factor of the vehicle body against rolking is greater than 2.5

Technical parameters of national VI diesel aviation catering vehicle

Engine model: 6HK1-TCG61

Transmission model: Allison2500

Platform working height (mm) : 2550-6200

Rated load of the box body (kg) : 6400

Rated load (kg) of the front platform: 3000

Rated load (kg) of the moving part of the front platform: 800

The left and right adjustment range (mm) of the front platform's active part: 0 to 700

The telescopic adjustment range (mm) of the front platform's movable part: 0 to 600

Dimensions of the fixed part of the front platform (length × width) (mm) : 1900×2265 [(1900×2265) (long and narrow)]/[(1400×2400) (short and wide)]/[(1900×2265) (long and narrow)]/[(1400×2400) (short and wide)]

The dimensions of the front platform's movable part (length × width) (mm) : 950×1200, 950×1200

Curb weight (kg) : 13,280

Overall dimensions (length × width × height) (mm) : 10400×2500×3700 (without canopy) /3800 (with canopy) /10400×2500×3700 (without canopy) /3800 (with canopy)

Chassis: QL5190TZZAEQHY

External dimensions of the box body (length × width × height) (mm) : 7500×2500×2400 7500/7200×2500×2400 0

Engine emissions: Emissions meet the requirements of the 6b stage in the sixth phase of GB 17691-2018 in China and the requirements of GB 3847-2018. Exhaust smoke density complies with the requirements of GB 3847-2018.

Rated load (kg) of the fixed part of the front platform: 2200
