JSTY5050GQS aircraft Water Service Truck product introduction

aircraft Water Service Truck product introduction

JSTY5050GQS aircraft Water Service Truck is a new type of airfield special vehicle which is refitted with the second class chassis. The chassis cab of the product is flat head, single row seat, two-door type, and the occupant is 3 people; The drive type is 4×2. Designed for a fixed work platform at the back, a large capacity water tank in the middle, the work platform is equipped with work lights, easy to work at night. The volume of the clean water tank is 3.0m³, the water supply flow is ≥150L/min, and the water supply pressure is 0.345Mpa.

Optional: lifting work platform. The height of the working platform from the ground is 400mm to 3000mm.

The product can be widely used in A300, A310, A318, A319, A320, A330, A340, B707, B727, B737, B747, B757, B767, B777, DC8, 1L-18, 1L-62, MD11, MD80 and other models.

The car has stable performance and low center of gravity. Good stability and maintainability. Safe and convenient operation. Reasonable structure design, advanced technology, beautiful appearance.

Technical parameter

Total length (mm):6355

Total width (mm):1900

Total height (mm):2150

Wheelbase (mm):3360

Wheel base (front/rear) (mm): 1385/1425

Front overhang (mm): 1090

Rear overhang (mm): 1905

Approach Angle (°) :21

Departure Angle (°) :6

Minimum ground clearance (mm) :200

Maintenance weight (kg) :3100

Total mass (kg) :6250

Channel circle Outer circle diameter (mm) :15500

Maximum driving range (km/h): 80

Tank volume (L) :3000

Water supply flow (L/min): ≥150

Water supply pressure (Mpa): 0.25~0.345

Minimum height of platform (mm): 400

Maximum height of working platform (mm): 3000

Water tank material: stainless steel plate 0Cr18Ni9Ti/3
