Self Propelled Ambulance Vehicle (Diesel semi-pilot type) is suitable for all types of aircrafts with door height between 1400~5800㎜, and it is also suitable for the boarding and disembarking of passengers with mobility disabilities. 1、The vehicle cannot be driven without the power take-off (P.T.O.) being removed, the compartment being lowered to the lowest position and...
On 20th March, 2024 (Wednesday), Xu Song, General Manager of Qingling Group, and his delegation visited Tianyi to exchange cooperation matters. Tianyi is a long-term partner of Qingling Group. Ma Haibing, the chairman of Tianyi, and Xu Zhigao, the general manager of Science and Innovation Centre, accompanied the whole visit to the equipment production workshop and Scien...
Diesel Garbage Vehicle can handle rubbish on B737, B747, B777, B787, A320 series, A330, A350 and other types of passenger aircraft. The total mass of our vehicle is 6200kg, the rated load of the compartment is 1900kg, the total mass of the vehicle is 8100kg, and the total mass of the chassis is 10495kg, which is not overweight in the industry. The total mass of the vehi...
Aircraft Potable water service truck chassis cab for the flat head, single seat, two-door type, passenger 2 people; drive type for 4 × 2, fresh water tank volume of 4m ³, fresh water flow ≥ 150L/min. Aircraft Potable water service truck The water pump is installed in the lower right front end of the box, directly connected with the outlet of the water tank, the water pu...
The chassis cab of toilet unloading vehicle is flat head, single-row seat, two-door type, with a crew of two; the drive type is 4×2, the volume of fresh water tank is 1.4m³, the volume of sewage tank is 2.4m³, the effective volume of circulating water tank is 0.24m³, the flow rate of fresh water is 90-150L/min; the flow rate of sucking sewage is 600L/min. This product ca...
Passenger boarding ladder ( hand-push ) applies to A318, A319, A320, A321, B707, B727, B737, DC-8/40/50F, DC8-61/61F, DC8-62/62F, DC8-63/63F, 1L-18 and other series of passenger aircraft passenger The passenger boarding ladder can be used as a hand-propelled ladder for passengers and also as a working ladder for flight attendants. This passenger boarding ladder is a han...
The top loading control part is mainly composed of relays, push button switches, sensors, and operation panel lights. The operation panel is divided into cab operation panel, The operation panel is divided into cab operation panel, upper operation panel of belt frame, and lower operation panel of belt frame. The belt frame operation panel mainly has the functions of conv...
1. It is not possible to drive the vehicle without the power take-off (P.T.O.) being removed, the compartment being lowered to the lowest position and the support being stowed, otherwise the engine of the vehicle in gear will stall. 2.When carrying out the operation, the support must be put into position first, if the support is not put, the compartment cannot be raised....
We are excited to share that we have successfully implemented a SACO Castor Deck system, built within a refrigeration unit, at Vagar Airport in the Faroe Islands. This innovation marks a significant step forward in supporting the new salmon export activities from the islands. This advanced facility has been specifically designed to meet the growing needs of the salmon ...
Towable Passenger Stair installed electrical line mainly includes lighting system, control system and height display instrument and other three parts. 1. Lighting system The lighting system consists of flat table lamps, ladder lights and warning lights. The control of the lighting system is transferred by the electrical box, wiring bar and sent to the flat table lamp, ...
Diesel Self Propelled Passenger Step Ladder adopts Qingling Class II chassis, Baosteel 960 high-strength steel as the ladder body, shrink type double ladder design, the width of the ladder body is 1.5m, the maximum Angle of the ladder body is 39.5°, and the maximum carrying capacity of the passenger step ladder is 64 people. The lifting range is designed to be 2.40m-5.8m...
TYAS290 Aircraft Starting Air Vehicle is used to directly start the big engine of the aircraft by outputting low-pressure and high-flow compressed air, and it can also be used to supply auxiliary air to the aircraft, for the inspection or air conditioning of the aircraft. It is a necessary ground support equipment for civil and military airports, aircraft maintenance bas...
Fire rescue ladder is composed of remote control chassis, movable ladder base, movable ladder, hydraulic outrigger, front support wheel, lifting cylinder, hydraulic system and electrical system. The remote control chassis is composed of chassis, front axle, rear axle, steering wheel, power battery, hydraulic power unit, electrical box, hand pump and step. Through the ha...
Flight Catering Hi Lift adopts Qingling QL1180XQFRY chassis. It is equipped with overhead camshaft, 6HK1-TCL water-cooled in-line direct injection 4-stroke diesel engine, with emission up to national V, integral cycle ball steering mechanism (with power steering), hydraulic double circuit pedal brake for starting, 24V DC electric system. The cab is equipped with cold and...
Catering highloader is suitable for C class models such as B737 and A320. 1. Body specifications: Overall dimensions (length × width × height, mm) : 5000×2010×2180. 2, the side panel and roof of the carriage are made of thermal insulation composite material, the thickness of the side panel is 30mm, the thickness of the roof is 70mm. The thickness of insulation floor is 6...
Ship Passenger Stair consists of base frame, fixed ladder, slide, soft connection platform, fine adjustment mechanism, hydraulic system and electrical system. Main technical performance parameters Maximum number of passengers (person): 60 Fixed ladder rungs: 14 Slide ladder rungs: 13 rungs Flip ladder rungs: 2 rungs Centre distance from front and rear support feet to m...
Electric Garbage Trucks is a manual chassis, the cab is flat head, single seat, two-door type, with a crew of 3; the drive type is 4×2; the vehicle has the features of easy and reliable operation, smooth lifting, beautiful shape, etc., and it can be applied to the use of aircrafts with the height of cabin door from 2.4 to 5.8 metres, with the volume of rubbish container ...
Electric Baggage Tow Tractor is a special equipment which is connected to the cargo flatbed truck through the traction bar and relies on the driving force generated by the electric drive system of the body to drive and tow the mobile cargo flatbed truck. The driving type is rear drive, and the braking type is front disc and rear drum. The whole vehicle layout type is clo...
1) The air start unit shall be equipped with a mechanical ball valve with automatic unloading function, which can quickly cut off the air supply to the aircraft; 2) The air source vehicle should be equipped with a pipe with standard aircraft connectors, each pipe length ≥ 12m, pipe internal diameter of 89mm, internal wire mesh, with anti-dragging wear and tear protection...
Electric Self Propelled Ambulance Vehicle is widely used on A300, A310, A318, A319, A320, A330, A340, B707, B727, B737, B747, B757, B767, B777, DC8, 1L-18, 1L-62, MD11, MD80, etc., except for Airbus A380 aircraft. B767, B777, DC8, 1L-18, 1L-62, MD11, MD80 and other models. The main features of Electric Self Promoted Ambulance Vehicle are as follows. 1. The chassis adopt...
Electric Potable Water Truck is designed as a rear-mounted lifting platform, with a large-capacity water tank in the middle, and the lifting platform is equipped with night-time operating lamps, which is convenient for night-time operation. The chassis cab of the product is a flat head, single-row seat, two-door type, with a crew of two; the drive type is 4×2, and the wa...
Electrical Lavatory Service Vehicle is a new type of special vehicle for collecting sewage and refilling fresh water for aircrafts in airports, our company has a total mass of 4700kg, fresh water and sewage tank volume of 5800L, the total mass of the whole vehicle is 10500KG, and the total mass of the chassis of Qingling is 10495+1049KG (the max. total mass cannot exceed...
JSTY5180JSPE Electric Aircraft Cleaning and Catering Trucks is a kind of airport ground special equipment produced by Jiangsu Tianyi Aviation Industry Co. The aviation food truck (electric type) mainly consists of QL1180BEVELQHY type II electric chassis, scissor type hydraulic lifting mechanism, liftable front platform, compartment, front and rear sliding doors, retracta...
JSTY5070KTE Electric self-propelled Passenger Stairs adopts Qingling EV100 electric chassis modified assembly, fixed ladder and sliding ladder, tail ladder, hydraulic system, electric system, canopy and other components. The energy-saving performance of pure electric power meets the demand of green environmental protection; the main supporting parts are all famous brand ...
STY5040JCSE Electric Self-propelled conveyor belt loader is a special vehicle with chassis independently developed by our company. It has advanced vehicle design concept, beautiful shape, reasonable layout and comfortable driving, and adopts ergonomic design. The transmission mechanism is fully functional and easy to operate, and the selection of well-known domestic acce...
Thanks to the proximity to his customers and their feedback, we have developed a range of aluminum runway and technical access stepladders, perfectly adapted to the height and size of aircraft of all types. Towable runway stepladder – mximal speed 5 km/h – steel frame hot galvanized – retractable steel towbar – adjustable in height from 3.75 to 5.50 meter by hydraulic ...
On February 4, 2024, Party Secretary and President of Jiangsu Council for the Promotion of International Trade (CCPIT), Mr. Wang Shanhua, Director of the Office of the CCPIT, Mr. Zheng Yuanlong, Director of the Trade Promotion Department, Mr. Wu Wenwen, and their entourage visited Tingyi to investigate the development of the enterprise and the results of the participatio...
Diesel semi-pilot Airport ambulift is suitable for all kinds of models with door height between 1400 and 5800㎜ Electrical system 1, mainly including the body lifting, support foot retracting, rear platform lifting control and special lighting instructions and other circuits. 2, the system is composed of operation box, operation panel, control switch, relay, lighting, mar...
Aircraft sewage truck is a new aircraft sewage collection and filling water special vehicle, rear lifting work platform, large capacity cleaning, sewage tank, hydraulic motor driven vacuum pump suction system (optional) and hydraulic motor driven stainless steel acid resistant pump, vacuum pump suction system can efficiently and conveniently provide suction service for a...
The height of WTJ5060JKT passenger boarding ladder body lifting platform is set to 2400mm ~ 5800mm, and has a fine-tuning function to adjust the height error between the passenger ladder platform and the aircraft door. It is suitable for A300, A310, A320, A330, A340, B737, B747, B757, B767, B777 and other models Product standard 1) MH/T6029-2014 "Passenger Stairway" 2) ...
TY-XC80 baggage belt loader mainly adopts advanced and mature products: Cummins original imported engine QSF2.8t3NA49, Japan Okamura Y43280D automatic transmission, Zhenjiang brake master pump and full hydraulic steering gear. The hydraulic system uses Italian or German control valve imported original parts. The steel structure of the body is welded by laser linear cutti...
JSTY5050GQS aircraft water truck The chassis cab of the product is flat head, single row seat, two-door type, occupant 3 people; The driving type is 4×2, which is designed to be fixed working platform at the back, large-capacity cleaning water tank in the middle, and working platform equipped with working light, which is convenient for night operation. The clean water ta...
WTJ5160JSP Airport catering vehicle is widely applicable to A300, A310, A318, A319, A320, A330, A340, B707, B727, B737, B747, B757, B767, B777, DC8, 1L-18, 1L-62, MD11, MD80 and other aircraft in addition to Airbus A380 Type of use. The main features of the product are as follows: ① The chassis adopts the Qingling Class II chassis, which has strong bearing capacity and ...
WTJ3600TKT hand-push passenger elevator platform from the ground height of 2640 ~ 3600mm, Suitable for A318, A319, A320, A321, B707, B727, B737, DC-8/40/50F, DC8-61/61F, DC8-62/62F, DC8-63/63F, 1L-18 and other series of passenger aircraft for boarding and boarding, and can also be used as a working ladder for the crew. As a hand-pushed non-motorized passenger ladder, th...
The Fire Brigade Helicopter Barracks are located inside the Bologna Airport and with them we studied the intervention for the replacement of old folding doors with new external sliding doors. This replacement of doors makes entry and exit of helicopters quick and easy, but above all these operations are performed in TOTAL safety. Furthermore, it guarantees the safety of ...
JSTY5060GQSE aircraft water vehicle (electric) The chassis cab of the product is flat head, single row seat, two-door type, and the occupant is 2 people; The drive type is 4×2, the clean water tank volume is 5.0m³, and the water supply flow is 220L/min. Qingling QL1070BEVECH2Y chassis Type II chassis, the company according to the product design for local modification. T...
